Ensure high temperature sample quality
DRS-2 adopts two-stage refrigerator, with PID precise temperature control, the sample temperature is controlled within 0℃~15℃±5℃,ensuring provide constant temperature and clean samples for the analyzer.
Optional automatic coke cleaner
The DRS-2 can be configured with an automatic coke cleaner, which can be manually or automatically removed periodically.
The residual blockage at the sample port ensures that the sampling port is unblocked.
Suitable for harsh industrial site
All components of DRS-2 are designed in strict working conditions. they are suitable for the site where the ambient temperature is -40℃~60℃ and the temperature is less than 850℃
sample sampling for corrosion and coking.
Long service life of sampler
DRS-2's remote manual/automatic back blow function completes high temperature regularly.
steam purge to eliminate tar residue in the sampler and prolong the use of the sampler life span.
On-site inspection free
Fully automatic operating DRS-2 can blowback function, which can reduce the field operations and the risk and difficulty of maintenance.
| Service analyzer | chromatography、optical analyzer、mass spectrum analyzer, etc |
| Sample inlet temperature | Maximum 700℃ |
| Sample inlet pressure | Maximum 6.5Mpa |
| Process inter face size | ANSI 2"150#RF（standard），pressure optional 300#、600#、900#，other specifications need to be customized by the manufacturer |
| Sample export size | 1/4" sleeve |
| Sample exit temperature | 0-15℃ ±0.5℃ |
| Sample outlet flow | 2-10L/min |
| Contact Sample material | 316SS（all parts of contact media） |
| Coke cleaner（optional） | Select according to the application, the length of the coke cleaner rod according to the site The international situation customized. |
| Output signal | RS485 communication |
| Explosion-proof grade | Meet Zone 1, IIC T4 |
| Ambient temperature | -40-60℃ |
| Working Power supply | 220VAC 50Hz，200W |
| Instrument air | 0.4-0.8Mpa，500L/min，1/2"sleeve connection |
| Steam（optional） | 0.4-0.8Mpa， 1/2"sleeve connection |
● Ethylene cracking units； ● ammonia synthesis units；
● Coal gasification units； ● catalytic cracking units；
● Ethylene units； ● more……
